GPUsed

Nvidia Quadro NVS 510 2GB DDR3 - A

Nvidia Quadro NVS 510 2GB DDR3 - A

Regular price £14.99 GBP
Regular price Sale price £14.99 GBP
Sale Just sold out!
Tax included. Shipping calculated at checkout.

Graphics Processor

GPU Name
GK107
GPU Variant
GK107-301-A2
Architecture
Kepler
Foundry
TSMC
Process Size
28 nm
Transistors
1,270 million
Density
10.8M / mm²
Die Size
118 mm²
Chip Package
BGA-908

Graphics Card

Release Date
Oct 23rd, 2012
Generation
NVS
Production
End-of-life
Launch Price
449 USD
Bus Interface
PCIe 2.0 x16
Reviews
26 in our database

Relative Performance

GeForce 210
36%
GeForce 9400 GT
46%
Radeon HD 4550
57%
Radeon HD 5450
73%
Radeon HD 6450
86%
GeForce GT 520
90%
NVS 510
100%
GeForce GT 220
112%
GeForce GT 430
146%
Radeon HD 5570
148%
Radeon HD 4670
161%
GeForce GT 440
170%
GeForce GT 240
173%
GeForce 9600 GT
199%
Radeon HD 5670
211%
GeForce GT 640
226%
GeForce 9800 GT
234%
Radeon HD 6670
244%
Radeon HD 4830
251%
Radeon HD 4770
268%
Radeon HD 4850
283%
GeForce GTS 250
289%
GeForce GTS 450
298%
Radeon HD 5750
308%
Radeon HD 7750
352%
Radeon HD 5770
355%
GeForce GTX 260
361%
Radeon HD 4870
365%
Radeon Vega 8
366%
GeForce GTX 550 Ti
370%
GeForce GTX 650
373%
Radeon HD 5830
395%
Radeon HD 6790
415%
Radeon HD 4890
422%
GeForce GTX 460
438%
Radeon RX Vega 11
441%
GeForce GT 1030
446%
GeForce GTX 275
450%
Radeon HD 7770 GHz Edition
451%
GeForce GTX 280
452%
GeForce GTX 465
461%
Radeon HD 6850
483%
GeForce GTX 285
492%
Radeon HD 5850
528%
GeForce GTX 650 Ti
538%
Radeon HD 7790
538%
Radeon RX 550
561%
GeForce GTX 470
562%
Radeon HD 6870
582%
Radeon HD 5870
621%
GeForce GTX 560 Ti
641%
Radeon HD 4870 X2
644%
GeForce GTX 750 Ti
656%
Radeon HD 6950
659%
GeForce GTX 295
682%
GeForce GTX 650 Ti Boost
690%
Radeon HD 7850
695%
GeForce GTX 480
707%
Radeon HD 6970
740%
Radeon R7 265
755%
Radeon RX 460
767%
Radeon R7 370
767%
GeForce GTX 660
769%
GeForce GTX 570
772%
Radeon RX 560
785%
GeForce GTX 950
833%
Radeon HD 7870 GHz Edition
840%
Radeon R9 270X
861%
GeForce GTX 660 Ti
872%
GeForce GTX 580
876%
GeForce GTX 1050
882%
Radeon HD 7950
885%
GeForce GTX 1630
901%
Radeon HD 5970
902%
GeForce GTX 760
927%
GeForce GTX 670
998%
GeForce GTX 960
1024%
Radeon R9 380
1050%
Radeon R9 285
1056%
Radeon HD 7970
1067%
GeForce GTX 680
1078%
GeForce GTX 1050 Ti
1103%
GeForce GTX 770
1132%
Radeon HD 6990
1158%
Radeon R9 280X
1186%
GeForce GTX 590
1203%
Radeon HD 7970 GHz Edition
1203%
GeForce GTX 780
1333%
Arc A380
1335%
Radeon RX 6400
1353%
GeForce GTX 1650
1381%
Radeon RX 470
1467%
Radeon R9 290
1487%
Radeon RX 570
1568%
Radeon R9 390
1587%
Radeon R9 290X
1595%
GeForce GTX 970
1617%
GeForce GTX TITAN
1638%
GeForce GTX 780 Ti
1660%
Radeon R9 390X
1684%
Radeon HD 7990
1691%
Radeon RX 480
1699%
GeForce GTX 690
1713%
GeForce GTX 1060 6 GB
1760%
Radeon RX 5500 OEM
1784%
Radeon RX 580
1806%
Radeon RX 5500 XT
1820%
Radeon RX 6500 XT
1835%
GeForce GTX 980
1843%
GeForce GTX 1650 SUPER
1859%
Radeon R9 FURY
1867%
Radeon RX 590
1950%
Radeon R9 295X2
2053%
GeForce GTX 1660
2065%
Radeon R9 FURY X
2089%
GeForce GTX 980 Ti
2124%
GeForce GTX TITAN X
2179%
GeForce GTX 1660 SUPER
2245%
GeForce GTX 1660 Ti
2370%
GeForce GTX 1070
2370%
GeForce RTX 3050 8 GB
2409%
Radeon RX Vega 56
2523%
GeForce GTX 1070 Ti
2676%
Radeon RX 5600 XT
2716%
Radeon RX Vega 64
2753%
GeForce GTX 1080
2791%
GeForce RTX 2060
2791%
Radeon RX 5700
2906%
Arc A580
2912%
Radeon RX 6600
3033%
GeForce RTX 2060 SUPER
3135%
GeForce RTX 2070
3176%
Radeon RX 5700 XT
3179%
GeForce RTX 3060 12 GB
3241%
Arc A750
3347%
Radeon VII
3365%
TITAN X Pascal
3452%
Radeon RX 6600 XT
3487%
GeForce GTX 1080 Ti
3556%
Arc A770
3591%
GeForce RTX 2070 SUPER
3594%
Radeon RX 6650 XT
3781%
Radeon RX 7600
3822%
GeForce RTX 4060
3840%
GeForce RTX 2080
3866%
Radeon RX 7600 XT
3944%
GeForce RTX 2080 SUPER
4053%
GeForce RTX 3060 Ti
4152%
Radeon RX 6700 XT
4298%
Radeon RX 6750 XT
4562%
GeForce RTX 4060 Ti 8 GB
4612%
GeForce RTX 2080 Ti
4646%
GeForce RTX 3070
4862%
GeForce RTX 3070 Ti
5203%
Radeon RX 7700 XT
5258%
Radeon RX 6800
5360%
GeForce RTX 4070
5939%
Radeon RX 6800 XT
6088%
GeForce RTX 3080
6319%
Radeon RX 7800 XT
6382%
Radeon RX 6900 XT
6560%
GeForce RTX 4070 SUPER
6889%
GeForce RTX 3080 Ti
7079%
Radeon RX 6950 XT
7087%
GeForce RTX 3090
7212%
GeForce RTX 4070 Ti
7393%
GeForce RTX 4070 Ti SUPER
8077%
Radeon RX 7900 XT
8295%
GeForce RTX 3090 Ti
8366%
GeForce RTX 4080
9392%
GeForce RTX 4080 SUPER
9533%
Radeon RX 7900 XTX
9624%
GeForce RTX 4090
11799%
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Performance estimated based on architecture, shader count and clocks.

Clock Speeds

GPU Clock
797 MHz
Memory Clock
891 MHz
1782 Mbps effective

Memory

Memory Size
2 GB
Memory Type
DDR3
Memory Bus
128 bit
Bandwidth
28.51 GB/s

Render Config

Shading Units
192
TMUs
16
ROPs
16
SMX Count
1
L1 Cache
16 KB (per SMX)
L2 Cache
256 KB

Theoretical Performance

Pixel Rate
3.188 GPixel/s
Texture Rate
12.75 GTexel/s
FP32 (float)
306.0 GFLOPS
FP64 (double)
12.75 GFLOPS (1:24)

Board Design

Slot Width
Single-slot
Length
160 mm
6.3 inches
TDP
35 W
Suggested PSU
200 W
Outputs
4x mini-DisplayPort 1.2
Power Connectors
None

Graphics Features

DirectX
12 (11_0)
OpenGL
4.6
OpenCL
3.0
Vulkan
1.2.175
CUDA
3.0
Shader Model
6.5 (5.1)

GK107 GPU Notes

NVENC: 1st Gen
NVDEC: 1st Gen
PureVideo HD: VP5
VDPAU: Feature Set D





Here's the GPUsed product grading system (currently only in place for GPUs)

A+ - New or Like new

A - Excellent / Very good for a used item (our most common grade)

B - Working (may have some cosmetic issues but won't affect performance)

C - Non working (we don't currently sell non working hardware)



View full details
