GPUsed

Powercolor AMD Radeon RX 6700XT Red Devil 12GB GDDR6 - A

Powercolor AMD Radeon RX 6700XT Red Devil 12GB GDDR6 - A

Regular price £279.99 GBP
Regular price Sale price £279.99 GBP
Sale Just sold out!
Tax included. Shipping calculated at checkout.

Product Description -



Summary - Great condition and performing well too, without the original box. Specifications below -



Graphics Processor

GPU Name
Navi 22
GPU Variant
Navi 22 XT
(215-127000006)
Architecture
RDNA 2.0
Foundry
TSMC
Process Size
7 nm
Transistors
17,200 million
Density
51.3M / mm²
Die Size
335 mm²
Chip Package
BGA-1701

Graphics Card

Release Date
Mar 3rd, 2021
Availability
Mar 18th, 2021
Generation
Navi II
(RX 6000)
Predecessor
Navi
Successor
Navi III
Production
Active
Bus Interface
PCIe 4.0 x16

Clock Speeds

Base Clock
2321 MHz
Game Clock
2424 MHz
Boost Clock
2581 MHz
Memory Clock
2000 MHz
16 Gbps effective

Memory

Memory Size
12 GB
Memory Type
GDDR6
Memory Bus
192 bit
Bandwidth
384.0 GB/s

Render Config

Shading Units
2560
TMUs
160
ROPs
64
Compute Units
40
RT Cores
40
L0 Cache
32 KB per WGP
L1 Cache
128 KB per Array
L2 Cache
3 MB
L3 Cache
96 MB

Theoretical Performance

Pixel Rate
165.2 GPixel/s
Texture Rate
413.0 GTexel/s
FP16 (half)
26.43 TFLOPS (2:1)
FP32 (float)
13.21 TFLOPS
FP64 (double)
825.9 GFLOPS (1:16)

Board Design

Slot Width
Dual-slot
Length
267 mm
260 mm
10.5 inches
10.2 inches
Width
110 mm
120 mm
4.3 inches
4.7 inches
Height
40 mm
49 mm
1.6 inches
1.9 inches
TDP
230 W
Suggested PSU
550 W
Outputs
1x HDMI 2.1
3x DisplayPort 1.4a
Power Connectors
1x 6-pin + 1x 8-pin
Board Number
109-D512A7-00_02

Graphics Features

DirectX
12 Ultimate (12_2)
OpenGL
4.6
OpenCL
2.1
Vulkan
1.3
Shader Model
6.7

Navi 22 GPU Notes

Generation: Navi II
Codename: Navy Flounder
Ray Tracing Cores: 1st Gen
Infinity Cache: 1st Gen
Graphics/Compute: 10.3.2
Shader ISA: GFX10.3 (gfx1031)
Display Core Next: 3.0.0
Video Core Next: 3.0.0
System DMA: 5.2.2
Platform Security Processor: 11.0.11

Per SIMD32:
- 10 KB Scalar Register File

Per CU:
- 16 KB Vector Data Cache
- 64 KB Local Data Share (GCN-Mode)

Per WGP:
- 16 KB Scalar Data Cache / K Cache
- 32 KB Instruction Cache
- 128 KB Local Data Share



This card has passed several tests. These tests include - A 1 hour run on Furmark (for temperature readings and to ensure stability), one run on each of Unigene’s Heaven and Superposition benchmarks (for performance figures in relation to brand new models) and we only buy cards in once they’ve passed all 3 tests and remained below 75°C, even under the extremely high loads of a 1 hour Furmark test. Finally, we perform a visual check to ensure it’s in good enough aesthetic condition before we buy the product in. This insures we never have stock we’re not happy with, so you never have to worry when buying from us!



All our cards are in good working condition as explained above. However, if you receive your order and it unfortunately doesn’t work, don’t panic, we have a 30 day return window, with money back guarantee. All so you can enjoy the bargain without being worried about any issues.



Here's the GPUsed product grading system (currently only in place for GPUs)

A+ - New or Like new

A - Excellent / Very good for a used item (our most common grade)

B - Working (may have some cosmetic issues but won't affect performance)

C - Non working (we don't currently sell non working hardware)



Feel free to check out our reviews on Google and Trustpilot for added piece of mind :

GPUsed - 4.9* Reviews on Trustpilot

GPUsed - 5* Reviews on Google


If you’re looking to sell a graphics card to us. Simply get in touch via the contact form at the following link for a personalised quote : https://www.gpused.co.uk/contact
