GPUsed

Nvidia RTX A5000 24GB GDDR6 - A

Nvidia RTX A5000 24GB GDDR6 - A

Regular price £1,199.99 GBP
Regular price Sale price £1,199.99 GBP
Sale Just sold out!
Tax included. Shipping calculated at checkout.

Product Description -



Summary - Used, working. Specifications below -



Graphics Processor

GPU Name
GA102
Architecture
Ampere
Foundry
Samsung
Process Size
8 nm
Transistors
28,300 million
Density
45.1M / mm²
Die Size
628 mm²
Chip Package
BGA-3328

Graphics Card

Release Date
Apr 12th, 2021
Generation
Quadro Ampere
(Ax000)
Predecessor
Quadro Turing
Successor
Quadro Ada
Production
Active
Bus Interface
PCIe 4.0 x16

Relative Performance

GeForce 210
1%
GeForce 9400 GT
1%
Radeon HD 4550
1%
Radeon HD 5450
1%
Radeon HD 6450
1%
GeForce GT 520
2%
GeForce GT 220
2%
GeForce GT 430
2%
Radeon HD 5570
3%
Radeon HD 4670
3%
GeForce GT 440
3%
GeForce GT 240
3%
GeForce 9600 GT
3%
Radeon HD 5670
4%
GeForce GT 640
4%
GeForce 9800 GT
4%
Radeon HD 6670
4%
Radeon HD 4830
4%
Radeon HD 4770
5%
Radeon HD 4850
5%
GeForce GTS 250
5%
GeForce GTS 450
5%
Radeon HD 5750
5%
Radeon HD 7750
6%
Radeon HD 5770
6%
GeForce GTX 260
6%
Radeon HD 4870
6%
Radeon Vega 8
6%
GeForce GTX 550 Ti
6%
GeForce GTX 650
6%
Radeon HD 5830
7%
Radeon HD 6790
7%
Radeon HD 4890
7%
GeForce GTX 460
7%
Radeon RX Vega 11
7%
GeForce GT 1030
8%
GeForce GTX 275
8%
Radeon HD 7770 GHz Edition
8%
GeForce GTX 280
8%
GeForce GTX 465
8%
Radeon HD 6850
8%
GeForce GTX 285
8%
Radeon HD 5850
9%
GeForce GTX 650 Ti
9%
Radeon HD 7790
9%
Radeon RX 550
10%
GeForce GTX 470
10%
Radeon HD 6870
10%
Radeon HD 5870
11%
GeForce GTX 560 Ti
11%
Radeon HD 4870 X2
11%
GeForce GTX 750 Ti
11%
Radeon HD 6950
11%
GeForce GTX 295
12%
GeForce GTX 650 Ti Boost
12%
Radeon HD 7850
12%
GeForce GTX 480
12%
Radeon HD 6970
13%
Radeon R7 265
13%
Radeon RX 460
13%
Radeon R7 370
13%
GeForce GTX 660
13%
GeForce GTX 570
13%
Radeon RX 560
13%
GeForce GTX 950
14%
Radeon HD 7870 GHz Edition
14%
Radeon R9 270X
15%
GeForce GTX 660 Ti
15%
GeForce GTX 580
15%
GeForce GTX 1050
15%
Radeon HD 7950
15%
GeForce GTX 1630
15%
Radeon HD 5970
15%
GeForce GTX 760
16%
GeForce GTX 670
17%
GeForce GTX 960
17%
Radeon R9 380
18%
Radeon R9 285
18%
Radeon HD 7970
18%
GeForce GTX 680
18%
GeForce GTX 1050 Ti
19%
GeForce GTX 770
19%
Radeon HD 6990
20%
Radeon R9 280X
20%
GeForce GTX 590
20%
Radeon HD 7970 GHz Edition
20%
GeForce GTX 780
23%
Arc A380
23%
Radeon RX 6400
23%
GeForce GTX 1650
23%
Radeon RX 470
25%
Radeon R9 290
25%
Radeon RX 570
27%
Radeon R9 390
27%
Radeon R9 290X
27%
GeForce GTX 970
27%
GeForce GTX TITAN
28%
GeForce GTX 780 Ti
28%
Radeon R9 390X
29%
Radeon HD 7990
29%
Radeon RX 480
29%
GeForce GTX 690
29%
GeForce GTX 1060 6 GB
30%
Radeon RX 5500 OEM
30%
Radeon RX 580
31%
Radeon RX 5500 XT
31%
Radeon RX 6500 XT
31%
GeForce GTX 980
31%
GeForce GTX 1650 SUPER
32%
Radeon R9 FURY
32%
Radeon RX 590
33%
Radeon R9 295X2
35%
GeForce GTX 1660
35%
Radeon R9 FURY X
35%
GeForce GTX 980 Ti
36%
GeForce GTX TITAN X
37%
GeForce GTX 1660 SUPER
38%
GeForce GTX 1070
40%
GeForce GTX 1660 Ti
40%
GeForce RTX 3050 8 GB
41%
Radeon RX Vega 56
43%
GeForce GTX 1070 Ti
45%
Radeon RX 5600 XT
46%
Radeon RX Vega 64
47%
GeForce GTX 1080
47%
GeForce RTX 2060
47%
Radeon RX 5700
49%
Arc A580
49%
Radeon RX 6600
51%
GeForce RTX 2060 SUPER
53%
GeForce RTX 2070
54%
Radeon RX 5700 XT
54%
GeForce RTX 3060 12 GB
55%
Arc A750
57%
Radeon VII
57%
TITAN X Pascal
59%
Radeon RX 6600 XT
59%
GeForce GTX 1080 Ti
60%
Arc A770
61%
GeForce RTX 2070 SUPER
61%
Radeon RX 6650 XT
64%
Radeon RX 7600
65%
GeForce RTX 4060
65%
GeForce RTX 2080
66%
Radeon RX 7600 XT
67%
GeForce RTX 2080 SUPER
69%
GeForce RTX 3060 Ti
70%
Radeon RX 6700 XT
73%
Radeon RX 6750 XT
77%
GeForce RTX 4060 Ti 8 GB
78%
GeForce RTX 2080 Ti
79%
GeForce RTX 3070
82%
GeForce RTX 3070 Ti
88%
Radeon RX 7700 XT
89%
Radeon RX 6800
91%
RTX A5000
100%
GeForce RTX 4070
101%
Radeon RX 6800 XT
103%
GeForce RTX 3080
107%
Radeon RX 7800 XT
108%
Radeon RX 6900 XT
111%
GeForce RTX 4070 SUPER
117%
Radeon RX 7900 GRE
119%
GeForce RTX 3080 Ti
120%
Radeon RX 6950 XT
120%
GeForce RTX 3090
122%
GeForce RTX 4070 Ti
125%
GeForce RTX 4070 Ti SUPER
137%
Radeon RX 7900 XT
141%
GeForce RTX 3090 Ti
142%
GeForce RTX 4080
159%
GeForce RTX 4080 SUPER
162%
Radeon RX 7900 XTX
163%
GeForce RTX 4090
200%
Based on TPU review data: "Performance Summary" at 1920x1080, 4K for 2080 Ti and faster.
Performance estimated based on architecture, shader count and clocks.

Clock Speeds

Base Clock
1170 MHz
Boost Clock
1695 MHz
Memory Clock
2000 MHz
16 Gbps effective

Memory

Memory Size
24 GB
Memory Type
GDDR6
Memory Bus
384 bit
Bandwidth
768.0 GB/s

Render Config

Shading Units
8192
TMUs
256
ROPs
96
SM Count
64
Tensor Cores
256
RT Cores
64
L1 Cache
128 KB (per SM)
L2 Cache
6 MB

Theoretical Performance

Pixel Rate
162.7 GPixel/s
Texture Rate
433.9 GTexel/s
FP16 (half)
27.77 TFLOPS (1:1)
FP32 (float)
27.77 TFLOPS
FP64 (double)
433.9 GFLOPS (1:64)

Board Design

Slot Width
Dual-slot
Length
267 mm
10.5 inches
Width
112 mm
4.4 inches
TDP
230 W
Suggested PSU
550 W
Outputs
4x DisplayPort 1.4a
Power Connectors
1x 8-pin
Board Number
PG132 SKU 500

Graphics Features

DirectX
12 Ultimate (12_2)
OpenGL
4.6
OpenCL
3.0
Vulkan
1.3
CUDA
8.6
Shader Model
6.8

GA102 GPU Notes

Ray Tracing Cores: 2nd Gen
Tensor Cores: 3rd Gen
NVENC: 7th Gen
NVDEC: 5th Gen
PureVideo HD: VP11
VDPAU: Feature Set K

Latest Drivers:
Windows 7 / 8 / 8.1 (x64):
GeForce Release 474.89

Windows 10 / 11 (x64):
GeForce Release: Latest
Quadro Release: Latest
Data Center Release: Latest

This card has passed several tests. These tests include - A 1 hour run on Furmark (for temperature readings and to ensure stability), one run on each of Unigene’s Heaven and Superposition benchmarks (for performance figures in relation to brand new models). Finally, we perform a visual check to ensure it’s in good enough aesthetic condition before we buy the product in. This insures we never have stock we’re not happy with, so you never have to worry when buying from us! If you’d like proof of any tests, just let us know and we’ll send the photos over for you :)



All our cards are in good working condition as explained above. However, if you receive your order and it unfortunately doesn’t work, don’t panic, we have a 30 day return window, with money back guarantee. All so you can enjoy the bargain without being worried about any issues.



Here's the GPUsed product grading system (currently only in place for GPUs)

A+ - New or Like new

A - Excellent / Very good for a used item (our most common grade)

B - Working (may have some cosmetic issues but won't affect performance)

C - Non working (we don't currently sell non working hardware)



Feel free to check out our reviews on Google and Trustpilot for added piece of mind :

GPUsed - 4.9* Reviews on Trustpilot

GPUsed - 5* Reviews on Google


If you’re looking to sell a graphics card to us. Simply get in touch via the contact form at the following link for a personalised quote : https://www.gpused.co.uk/contact

View full details

If you have anymore questions, please fill out our contact form.

FAQs

Are all of your items used?

They are mostly used due to the nature of our business, we buy and sell used tech from several suppliers and sometimes individuals too. To ensure they're still fully functional and their longevity hasn't been affected, we test each item intently and are still yet to have a single return due to it not meeting the customer's expected standards!

How can I part exchange?

If you're upgrading and looking to part exchange, simply head over to the contact form on our website for a bespoke quote and further details of how the part exchange process works.

What postal service do you use?

We use Royal Mail tracked 24 or 48, depending on the value of the item, if you select standard postage at checkout. However, for the speediest, safest postal service - select Royal Mail 1pm at checkout and you'll have it by 1pm the day after dispatch for just a bit extra.

Greater detail will be available when you go to checkout.

What's your returns policy?

Our returns policy can be found in the footer alongside our other policies. But to save some time, we usually offer a 30 day returns policy for any item that doesn't live up to the standards advertised on our site. That is 30 days from receipt of the item at your end to receipt of the item at our end, giving you sufficient time to test and make sure it's working as it should. We've been operating for nearly 2 years now and are yet to have anything returned due to our in depth testing of cards before we even list them for sale, so hopefully we can keep this up!

What's the best way to get in touch with you?

Head over to our contact page for the easiest way to get in touch, when you fill out the contact form, the information is emailed straight to us. Or you can email directly at Max@GPUsed.co.uk or via phone at 07896542603.

How can I see your reviews?

You can see reviews for each indivdual product on the shop section, however, as we haven't sold hundreds of each individual graphics card type, this may not be sufficient for you. So head over to our Trustpilot to put your mind at ease https://uk.trustpilot.com/review/gpused.co.uk.

Where do the donations go?

If you checkout to buy an item with us you'll notice an option to donate, all proceeds from donations are given to our chosen charity. This charity was voted for by our previous customers in the first 2 weeks of 2023. The most voted charity was lendwithcare.org. Click on 'Donations' for more info.

Where are you based?

We're based in East Yorkshire, but we dispatch sales every day, so you can order online, even if you live nearby! If you are thinking about collecting or dropping off an item with us then get in touch and we'll help you find us!
